Cross joints are small axles with needle bearing or hardened bushes. Series 0.600 and 0.700 joints in single or double. Torque 6-250/450 Nm. Max. angle 45 degrees. Max. rpm series 0.600 up to 5,000 rpm and series 0.700 up to 1,000 rpm. Material 9 SMn Pb 28k No. 1.0718. Other sizes and types on request.

A cardan shaft is a shaft for power transmission equipped with a universal joint. Cardan shafts are best known from rear-wheel drive and front-engine vehicles. Also in industrial applications,the cardan shaft is used to transmit the torque and compensate for misalignment.

Cardan shafts are complete shafts, and typically consist of a cardan (the middle part itself), and at each end there is a welding fork that is connected to a cross joint which is in turn connected to the flange.

Series 0.100. Elbe cardan shafts with extension offers torque up to 35,000 Nm. Max. bending angle up to 35 degrees. With flange or hub (shaft connection) or with welding stud.

If you do not find the right product for your application here on the pages, or if you need guidance, then you are welcome to contact us.
